4J33 Nickel Based Precision Alloy Strip


Availability:

Quantity:



Inquire Add to Basket

Material: 4J33, 1J22, 1J50, 1J85, 1J79, 4J36, 4J50, 4J29, 4J52
Cold Rolled Thickness: 0.15-4mm
Hot Rolled Thickness: 4-22mm
Width: ≤200mm
Surface: Bright, Original
Application: Resistor, Heating Element, Resistance Furnace, Household Appliances, Precision Instruments & Meters, etc.
Packing: In Coils - Woven Bag - Pallet or Wooden Case

Precision Alloy Nickel Based Alloy Precision Alloy Strip Nickel Based High Temperature Alloy 4J33 Alloy Steel Strip Steel Alloy Strip

Product Description

Application

Download

4J33 Nickel Based Precision Alloy Strip

4J33
Chemical Composition %	Ni: 32.1-33.6	P: ≤0.02	Fe: Margin
	Mn: ≤0.50	S: ≤0.02	Si: ≤0.3
	C: ≤0.03	Co: 14.0-15.2
Application Area	Used for making iron nickel cobalt alloy strips, bars, plates, and pipes that are matched and sealed with hard glass, used for emission tubes, oscillation tubes, ignition tubes, transistors, as well as electric vacuum devices such as tube sealing plugs and relay shells

Alloy Grade

Chemical Composition %

C

P

S

Mn

Si

Cu

Cr

Mo

Ni

Co

Fe

Remark

1J36

≤0.03

≤0.02

≤0.06

≤0.20

-

35.0-37.0

Margin

1J50

≤0.03

≤0.02

0.30-0.60

0.15-0.30

≤0.20

-

49.0-50.5

-

Margin

1J79

≤0.03

≤0.02

0.60-1.10

0.30-0.50

≤0.20

3.80-4.10

78.5-80.0

Margin

1J80

≤0.03

≤0.02

0.60-1.10

1.10-1.50

≤0.20

2.60-3.00

-

79.0-81.5

-

Margin

3J9

0.02-0.26

≤0.03

≤0.02

1.80-2.20

1.3-1.70

19.0-20.5

1.60-1.85

9.0-10.5

Margin

4J29

≤0.03

≤0.02

≤0.50

≤0.30

≤0.20

28.5-29.5

16.8-17.8

Margin

4J28

≤0.12

≤0.02

≤1.00

≤0.90

27.0-29.0

≤0.50

Margin

N≤0.02

4J42

≤0.05

≤0.02

≤0.80

≤0.30

41.5-42.5

≤1.0

Margin

Al≤0.10

4J50

≤0.05

≤0.02

≤0.80

≤0.30

49.5-50.5

Margin

Al≤0.10

In 4J29: Al: ≤0.10% , Mg: ≤0.10% , Zr: ≤0.10% , Ti: ≤0.10%，Al+Mg+Zr+Ti: ≤0.20%

7*24 Hours Service

Have an excellent after-sales service team to ensure that the first time to solve customer after-sales problems.

Reasonable Price

More than 10 precision production line, easy to realize large quantities of goods, to provide you with the best price.

1

Plate/Strip Cutting

We can cut the sheet plates and strips as you required.

2

Surface Treatment

We offer different surface treatments like brushed, mirror, painting etc. for your sheet, strips.

3

Laser Cutting

We offer laser cutting service for your OEM requirements.

4

Material Process

We can make flanges, springs, woven belts, curly furnace wires, etc.

High-temperature nickel-based alloys are widely used in electric resistance heating applications, primarily due to their excellent high-temperature stability, oxidation resistance, corrosion resistance, and favorable electrical resistivity properties.

Electric Heat and Resistance
High-temperature nickel-based alloys are widely used in high-temperature industrial equipment due to their excellent thermal stability, oxidation and corrosion resistance, and superior mechanical strength at elevated temperatures.

High Temperature Industrial Equipment
High-temperature nickel-based alloys are widely used in the petrochemical industry under high-temperature, high-pressure, and highly corrosive environments due to their excellent heat resistance, corrosion resistance, and creep resistance.

Petrochemical Industry
High-temperature nickel-based alloys have become critical materials for modern aerospace engines and high-temperature components due to their exceptional high-temperature strength, oxidation resistance, creep resistance, and fatigue resistance.

Aerospace Industry
